APC NetShelter WX 12U Wall Mount Cabinet

Product details

Compare mounting compatibility, size range and load limits for your workspace.

Quick comparison

• Product: APC NetShelter WX 12U Wall Mount Cabinet
• Product SKU: UPA-AR112

Before you order

Confirm the device’s mounting pattern and weight, plus the desk or wall fixing requirements. Check the listed compatibility before ordering.

Buying for a Sydney business? Request a business quote for quantities, compatibility and deployment requirements.

Full product details

APC NetShelter 12U Wallmount Rack Cabinet Single Hinged Server Depth Unassembled Presentation Ideal for retail

• healthcare
• and educational facilities
• the wall rack offers an efficient solution for deploying server and networking equipment for edge computing applications. For areas with limited floor space. Designed to house your server
• as well as network solutions such as network switches and patch panels. Rack hinges at the rear allowing for access to the back of the rack during installation and setup or while undergoing maintenance. The door is reversible allowing for the door to open direction desired to avoid interference with its surroundings. Optional 120V fan tray top-mounted and caster kit. Several APC Smart-UPS models low-profile provide easy UPS integration and mounting. 12U Wall mount cabinet
• 16.8 to 20.8 inches mounting depth
• 200lb weight capacity
• 19" rack width
• ships unassembled
• 5 year APC warranty. Product or Component Type Rack enclosure Number of rack unit 12U Physical Height 24.41 in (62 cm) Width 23.58 in (59.9 cm) Depth 23.58 in (59.9 cm) Product Weight 40.30 lb(US) (18.28 kg) Color Black Mounting Support Wall Mounting preference No preference Mounting Mode Not rack-mountable Maximum Mounting Depth 20.80 in (52.83 cm) Minimum Mounting Depth 16.80 in (42.67 cm) Rack Width 19" Permanent permissible load 200 lb(US) (90.72 kg) static Conformance Standards EIA-310E
