TP-Link TL-SF1008P 8-Port 10/100Mbps Desktop Unmanaged Switch 4-Port PoE 57W IEEE 802.3af, Fanless

Product details

Compare the listed ports, connection standards and management requirements for your network.

Quick comparison

• Ports: 8-Port
• Listed network standard or speed: 10/100Mbps
• Listed PoE standard: 802.3af
• Product SKU: NWTL-SF1008P

Before you order

Confirm compatibility with your existing network, power or PoE requirements and any required licences or subscriptions. Plan configuration and deployment before ordering.

Buying for a Sydney business? Request a business quote for quantities, compatibility and deployment requirements.

Full product details

TL-SF1008P is an 8 10/100Mbps ports unmanaged switch that requires no configuration and provides 4 PoE (Power over Ethernet) ports. It can automatically detect and supply power with all IEEE 802.3af compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.

HARDWARE FEATURES

Interface — 8 10/100Mbps RJ45 Ports

AUTO Negotiation/AUTO MDI/MDIX

Network Media — 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

100BASE-TX: UTP category 5, 5e cable (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

Fan Quantity — Fanless

Power Consumption — Maximum (PoE on): 60.2W (220V/50Hz)

Maximum (PoE off): 3.2W (220V/50Hz)

External Power Supply — External Power Adapter(Output: 48VDC / 1.25A)

PoE Ports (RJ45) — Standard: 802.3 af compliant

PoE Ports: Port1- Port4

Power Supply: 57W

Backbound Bandwidth — 1.6Gbps

Mac Address Table — 2K

Dimensions ( W x D x H ) — 6.7*3.9*1.1 in. (171*98*27 mm)
