Zippy 2U Form, Output 600W, Best Solution for Server, Workstation, Storage System, IPC

Product details

Review the product details and listed configuration to match this item to your business requirements.

Quick comparison

• Output 600W
• Best Solution for Server
• Workstation
• Storage System
• Product SKU: PSZ-P2G-5600G

Before you order

Confirm the exact model, compatibility, included components and any installation or support requirements before ordering.

Buying for a Sydney business? Request a business quote for quantities, compatibility and deployment requirements.

Full product details

INPUT SPEC VOLTAGE: 90 ~ 264 VAC FULL RANGE FREQUENCY: 47 ~ 63 HZ INPUT CURRENT: 9A(RMS) FOR 115VAC

• 4.5A(RMS) FOR 230 VAC INRUSH CURRENT: 50A MAX. FOR 115 VAC
• 100A MAX. FOR 230 VAC POWER FACTOR CORRECTION: PFC CAN REACH THE TARGET OF 95% AT 115/230VAC
• FULL LOAD FEATURES ‧TEMPERATURE RANGE: OPERATING 0℃ ~ 50℃
• STORAGE –20℃ ~ 80℃ ‧HOLD UP TIME: 16 ms MINIMUM AT FULL LOAD NORMAL INPUT VOLTAGE ‧EFFICIENCY: 87~90% TYPICAL AT 115V
• FULL LOAD ‧LEAKAGE CURRENT: 3.5mA MAX. AT NOMINAL VOLTAGE VAC ‧POWER GOOD SIGNAL: ON DELAY 100 ms TO 500 ms
• OFF DELAY 1 ms ‧OVER POWER PROTECTION: 110~160% ‧OVER VOLTAGE PROTECTION: +3.3V→3.6~4.3V
• +5V→5.6~6.5V
• +12V→13.2~15V ‧OVER CURRENT PROTECTOIN: +3.3V→27.5~40A
• +5V→27.5~40A
• +12V→52.8~72.8A ‧SHORT CIRCUIT PROTECTION ‧EMI: FCC CLASS B
• CISPR22 CLASS B ‧SAFETY: TO MEET UL
• CUL
