AOC 23.8-inch IPS 1ms 120hz | FHD 1920×1080@100Hz – HDMI | 1920×1080@60Hz – VGA. VESA 100 x 100

Product details

Compare screen size, resolution, refresh rate and video connections for your office desks.

Quick comparison

• Screen size: 23.8-inch
• Resolution: 1920×1080
• Refresh rate: 120hz
• Product SKU: MNAO-24B3HA3

Before you order

Check your computer’s video outputs, required cables and desk or monitor-arm fit. A USB-C port does not necessarily support video input or enough power to charge your laptop.

Buying for a Sydney business? Request a business quote for quantities, compatibility and deployment requirements.

Full product details

AOC 23.8' IPS 1ms 120hz, Ultra Slim, Speakers, Flicker Free, FHD 1920×1080@100Hz – HDMI, 1920×1080@60Hz – VGA. VESA 100 x 100, Earphone.Office Monitor

24B3HA3 is a Full HD display with IPS wide viewing angle, Incredible, 120Hz refresh rate, and 1ms response time, 3-side frameless. This IPS display deliver 178/178-degree viewing angles while maintaining consistent image quality and colors from all viewing positions.

Specifications

Panel — 23.8' / IPS

Pixel Pitch (mm) — 0.2745 (H) × 0.2745 (V)

Effective Viewing Area (mm) — 527.04 (H) × 296.46 (V)

Brightness (typical) — 250 cd/m²

Contrast Ratio — 1300 : 1 (typical) 20 Million : 1 (DCR)

Response Time — 4ms GtG / 1ms MPRT

Viewing Angle — 178° (H) / 178° (V) (CR > 10)

Color Gamut — NTSC 83% (CIE1976) / sRGB 100% (CIE1931)

Color Accuracy — -

Optimum Resolution — 1920 × 1080 @ 100Hz – HDMI, 1920 × 1080 @ 60Hz – VGA

Display Colors — 16.7 Million

Signal Input — VGA × 1, HDMI 1.4 × 1

HDCP Version — -

USB Hub — No

Power Supply — 100 - 240V～1.5A, 50 / 60Hz

Power Consumption (typical) — 30W

Speakers — 2W × 2

Line in & Earphone — Earphone × 1

Wall-Mount — 100mm × 100mm

Adjustable Stand — Tilt: -5° ~ 23°

Product without Stand (mm) — 316.2 (H) × 542.4 (W) × 44.6 (D)

Product with Stand (mm) — 412.1 (H) × 542.4 (W) × 202.3 (D)

Packaging (mm) — 394 (H) × 614 (W) × 126 (D)

Product without Stand (kg) — 2.65

Product with Stand (kg) — 2.97

Product with Packaging (kg) — 4.65

Cabinet Color — Black

Regulatory Approvals — CE / FCC / RoHS

What's in the box — HDMI Cable 1.8m × 1
