Shop / Catalogue / Simplecom EC315 PCIe x4 to 4-Port USB 3.2 Gen II 10Gbps Type-C and Type-A with Front Panel USB 3.0 and USB-C Key-A Expansion Card

Simplecom EC315 PCIe x4 to 4-Port USB 3.2 Gen II 10Gbps Type-C and Type-A with Front Panel USB 3.0 and USB-C Key-A Expansion Card

Simplecom EC315 PCIe x4 to 4-Port USB 3.2 Gen II 10Gbps Type-C and Type-A with Front Panel USB 3.0 and USB-C Key-A Expansion Card

$54.00 incl. GST$49.09 ex GST
Skip to product information
Simplecom EC315 PCIe x4 to 4-Port USB 3.2 Gen II 10Gbps Type-C and Type-A with Front Panel USB 3.0 and USB-C Key-A Expansion Card
  • Simplecom EC315 PCIe x4 to 4-Port USB 3.2 Gen II 10Gbps Type-C and Type-A with Front Panel USB 3.0 and USB-C Key-A Expansion Card
  • Simplecom EC315 PCIe x4 to 4-Port USB 3.2 Gen II 10Gbps Type-C and Type-A with Front Panel USB 3.0 and USB-C Key-A Expansion Card
Simplecom EC315 PCIe x4 to 4-Port USB 3.2 Gen II 10Gbps Type-C and Type-A with Front Panel USB 3.0 and USB-C Key-A Expansion Card

Simplecom EC315 PCIe x4 to 4-Port USB 3.2 Gen II 10Gbps Type-C and Type-A with Front Panel USB 3.0 and USB-C Key-A Expansion Card

$54.00 incl. GST$49.09 ex GST
In stock

Product details

Review the product details and listed configuration to match this item to your business requirements.

Quick comparison

  • Product: Simplecom EC315 PCIe x4 to 4-Port USB 3.2 Gen II 10Gbps Type-C and Type-A with Front Panel USB 3.0 and USB-C Key-A Expansion Card
  • Product SKU: MBSI-EC315

Before you order

Confirm the exact model, compatibility, included components and any installation or support requirements before ordering.

Buying for a Sydney business? Request a business quote for quantities, compatibility and deployment requirements.

Full product details

Simplecom EC315 PCIe x4 to 4-Port USB 3.2 Gen II 10Gbps Type-C and Type-A with Front Panel USB 3.0 and USB-C Key-A Expansion Card Quick Overview - PCIe x4 expansion card

  • also compatible PCIe x8 or x16 slot - USB 3.2 Gen 2 interface supports data transfer rates of up to 10Gbps - Integrated PCIe to USB 3.2 Gen 2 controller and USB 3.2 Gen 2 hub controller - The USB ports on the rear panel and front panel can operate simultaneously - Two rear panel connectors
  • 1x USB-C and 1x USB-A port - Two internal connectors for front panel
  • USB 3.0 19/20-Pin and Key-A (Type-E) connectors - Backwards compatible with USB 2.0 and USB 1.1 devices - Built-in over current protection on each USB port - Powered by PCIe
  • no external power required - Built-in PCIe 12V to 5V modules provide power to USB ports - Plug and play
  • automatic installation on Windows Specifications PCIe Interface: PCIe 3.0 x4
  • compatible PCIe x8 or x16 slot USB Standard: USB 3.2 Gen 2 10Gbps Rear Panel Connectors: 1x USB-A
  • 1x USB-C Internal Connectors for Front Panel: 1x USB 3.0 19/20Pin socket (Front USB-A)
  • 1x Key-A (Type-E) connector (Front USB-C) USB Speed Support: SuperSpeed+ (10Gpbs)
  • SuperSpeed (5Gpbs)
  • HiSpeed (480Mbps)
  • Full Speed (12Mbps) USB Power Source: Integrated PCIe 12V to 5V module Operating System Support: Windows 7 and above Package Contents 1x USB 3.2 Gen 2 Expansion Card 1x Low Profile Bracket System Requirement 1x available PCle 3.0 or higher x4/x8/x16 slot on motherboard
  • please note PCIe 1.0 or 2.0 x4 slot bandwidth is lower than 10Gbps Plug and play for Windows 8 and above operating system
