DeepCool AK700 VC Vapor Chamber Air Cooler, 7 Heat Pipes, 4-pin PWM, Intel LGA1851/1700/1200/115x, AMD AM5/AM4

Product details

Review the product details and listed configuration to match this item to your business requirements.

Quick comparison

• 7 Heat Pipes
• 4-pin PWM
• Intel LGA1851/1700/1200/115x
• AMD AM5/AM4
• Product SKU: CFD-AK700-VC

Before you order

Confirm the exact model, compatibility, included components and any installation or support requirements before ordering.

Buying for a Sydney business? Request a business quote for quantities, compatibility and deployment requirements.

Full product details

AK700 VCThe AK700 VC pushes the legendary AK series to the next level. Armed with the second generation of vapor chamber base, seven advanced copper heat pipes, and a dense single-tower heatsink, it delivers enhanced heat transfer and greater cooling capacity for today’s most demanding CPUs.

Application For

Intel

LGA1851/1700/1200/1151/1150/1155

AMD

AM5/AM4

Technical Spec

Product Dimensions — 126×98×157 mm(L×W×H)

Heatsink Dimensions — 124×76×151 mm(L×W×H)

Net Weight — 1248 g

Heatpipe — Ø6 mm×7 pcs

Fan Dimensions — 120×120×25 mm(L×W×H)

Fan Speed — 2700±10% RPM(max)

Fan Motor — 3-phase，12-slot，10-pole

Fan Airflow — 80.37 CFM

Fan Air Pressure — 4.98 mmAq

Fan Noise — 36.0 dB(A)

Fan Connector — 4-pin PWM

Bearing Type — Fluid Dynamic Bearing

Fan Rated Voltage — 12 VDC

Fan Rated Current — 0.41 A

Fan Power Consumption — 4.92 W
